LOA 91,76 m Beam 21,6 m Draft 4,25 m Built in year 1990, rebuilt in 2001 Flag : [Unknown] Gross Tonnage of 3.332 and Nett Tonnage of 999 4 legs of 32m length 1 Crane / Gear installed with a max lifting capacity of 110 tons 1 Crane / Gear installed with a max lifting capacity of 27 tons Free Deck area about 1.020m² with a deck strength of 2 metric tonnes per square meter Deadweight : 2.753 metric tonnes Ice strength Total passenger capacity 16 Speed : 8,5 knots Engines : 2 x MaK / Krupp Mak Maschinenbau - GFR 6M332C, 2.400 kw, 900 rpm, Propellers 1 Controllable Pitch (Port Side) + ... read more

General Particulars Built 2009/2010 Dimensions Vessels are normally always supplied in a 19m x 12m configuration they can also be supplied in 12m X12m, 18m x 18m configuration based on project requirements. C5 Quadra float units - Each 12.2m X 3.05m X 1.52m C5 Duo float units – Each 6.1m x 3.05m x 1.52m Dimensions can be any combination of the above units as per customer spec and requirements once it forms a safe platform which meets minimum floating and elevated stability criteria. Barge assembly layout can be altered to suit customers’ requirements. (I.e. Extra Moon pools) Legs &... read more

LOA 133 m Beam 53 m Draft 7 m Built in year 2024 Class : China Classification Society Flag : China Gross Tonnage of 25.084 and Nett Tonnage of 7.525 4 legs of 120m length for max water depth of 65m Dynamic Positioning of class : DP 2 1 Crane / Gear installed with a max lifting capacity of 2200 tons 1 Crane / Gear installed with a max lifting capacity of 300 tons 1 Crane / Gear installed with a max lifting capacity of 50 tons Free Deck area about 4.800m² with a deck strength of 15 metric tonnes per square meter Deadweight : 9.000 metric tonnes Ice classed 1D Total 120 berths Speed :... read more

JACKING SYSTEM Maker : SAMBO C.M.C Capacity lifting : 3,600 TON Capacity holding : 4,800 TON Jacking speed up : 40 M/hour (max) Jacking speed down : 40 M/hour (max) OPERATING CONDITIONS Water Depth : 40.00 M Wave Height : 2.50 M Vave Period : 8.0 s Current Veleocity : 5.0 m/s Wind Velocity : 38.0 m/s Leg Penetration max : 6.00 M DIMENSIONS Air gap : 3.00 M SURVIVAL CONDITIONS Water Depth : 20.00 M Wave Height : 4.70 M Wave Period : 6.0 s Current Veleocity : 5.0 m/s Wind Velocity : 58.0 m/s Leg Penetration max : 6.00 M Air gap : 6.00 M LOA 50 m Beam 28 m Draft 3,01 m Built in year 2015... read more

The Jack-Up is a multi-purpose jack-up barge design, which offers solutions to all kinds of maritime operations such as offshore construction. It can be modified to fit your demands. This could either be the installation of propulsion, or the installation of a heavy lift crane to fit your project. Bureau Veritas I ? HULL • MACH Offshore Self Elevating Unit assisted propulsion, Coastal Area, Transit over 20 miles from shore with HS < 2.5m LOA 50 m Beam 25 m Draft 3,1 m Built in year 2025 4 legs of 66m length for max water depth of 40m Total 40 berths... read more

LOA 139,2 m Beam 48 m Draft 6,5 m Built in year 2024 Class : China Classification Society Flag : China Gross Tonnage of 17.909 and Nett Tonnage of 5.372 Dynamic Positioning of class : DP 2 1 Crane / Gear installed with a max lifting capacity of 1600 tons 1 Crane / Gear installed with a max lifting capacity of 250 tons Deadweight : 8.762 metric tonnes Ice classed 1D Speed : 8 knots Engines : 1 x Unknown Builder, Propellers 1 x Center... read more

LOA 108 m Beam 47,5 m Draft 5,1 m Built in year 2016 Class : Bureau Veritas Flag : France Gross Tonnage of 9.242 and Nett Tonnage of 2.772 8 legs of 55m length Dynamic Positioning of class : DP 1 1 Crane / Gear installed with a max lifting capacity of 4400 tons 1 Crane / Gear installed with a max lifting capacity of 110 tons 1 Crane / Gear installed with a max lifting capacity of 25 tons 1 Crane / Gear installed with a max lifting capacity of 6 tons Free Deck area about 1.875m² with a deck strength of 30 metric tonnes per square meter Deadweight : 6.086 metric tonnes Total 12 berths ... read more

LOA 139,2 m Beam 48 m Draft 6,5 m Built in year 2024 Class : China Classification Society Flag : China Gross Tonnage of 17.856 and Nett Tonnage of 5.356 Legs of 120m length for max water depth of 70m Dynamic Positioning of class : DP 2 1 Crane / Gear installed with a max lifting capacity of 1600 tons 1 Crane / Gear installed with a max lifting capacity of 250 tons Deadweight : 6.600 metric tonnes Total passenger capacity 118 with 118 berths Engines : 1 x Daihatsu / CSSC Anqing-Kiel 8DK-28, 2.800 kw, 750 rpm, Propellers 1 Directional (Aft) Auxiliaries Engines : Bowthruster + No Ster... read more

LOA 59,8 m Beam 28 m Draft 3,2 m Built in year 2016 Class : Russian Maritime Register Flag : Cyprus Gross Tonnage of 2.162 and Nett Tonnage of 648 4 legs of 52m length Deadweight : 3.551 metric tonnes Engines : Unknown Builder... read more
