Description

LOA 91,76 m
Beam 21,6 m
Draft 4,25 m

Built in year 1990, rebuilt in 2001
Flag : [Unknown]
Gross Tonnage of 3.332 and Nett Tonnage of 999

4 legs of 32m length
1 Crane / Gear installed with a max lifting capacity of 110 tons
1 Crane / Gear installed with a max lifting capacity of 27 tons
Free Deck area about 1.020m² with a deck strength of 2 metric tonnes per square meter
Deadweight : 2.753 metric tonnes
Ice strength

Total passenger capacity 16

Speed : 8,5 knots
Engines : 2 x MaK / Krupp Mak Maschinenbau - GFR 6M332C, 2.400 kw, 900 rpm, Propellers 1 Controllable Pitch (Port Side) + 1 Controllable Pitch (Starboard)
Auxiliaries Engines : 1 Scania 469 kw, Bowthruster + No Sternthruster (1 Bow Tunnel thruster)

Specifications

Engine(s)

2 x 2.400 kw, 900 rpm, MaK / Krupp Mak Maschinenbau - GFR 6M332C,
Propellers: 1 Controllable Pitch (Port Side) + 1 Controllable Pitch (Starboard)
