Description

Length Overall: 53.37 m Breadth : 9.76 m Draft: 2.13 m
Main Engines: 4 × Caterpillar 1,875 BHP 7,200 BHP (Total)
Propulsion: 4 × Hamilton HM811 Waterjets + 2 × 200 HP Bow Thrusters
Builder: Midship Maine Inc, USA( 2006)
Speed: 30 kn (max) / 20 kn (full load)
Deck Cargo: 223 T on 242 m² @ 2.5 t/m²
Capacities: FO 142 m³ | Drill Water 112 m³ | Fresh Water 7.6 m³
Accommodation: 74 passenger seats -10 crew (4 × 1-man, 3 × 2-man cabins)
Fire-fighting: 2 × Monitors (1,260 m³/hr each), 2 × Pumps (1,200 m³/hr each)
DPS-2 System fully compliant with ABS class requirements
LOA 53.37 m
Beam 9.76 m
Draft 2.13 m

Built in year 2006
Class : American Bureau of Shipping
Flag : Liberia
Gross Tonnage of 454 and Nett Tonnage of 136

Total passenger capacity 74

Deadweight : 316 metric tonnes
Dynamic Positioning of class : DP 2
Free Deck area about 242m² with a deck strength of 2.5 metric tonnes per square meter
Fire Fighting System installed

Speed : 20 knots
Engines : 4 x Caterpillar / Caterpillar KTA-50-M2, 7,200 kw, 1,900 rpm, Propellers 1 Water Jet (Port Side Inner) + 1 Water Jet (Port Side Outer) + 1 Water Jet (Starboard Inner) + 1 Water Jet (Starboard Outer)
Auxiliaries Engines : 1 Cummins 200 kw, Bowthruster + No Sternthruster (2 Bow Tunnel thruster 147kw)

Specifications

Engine(s)

4 x 7,200 kw, 1,900 rpm, Caterpillar KTA-50-M2,
Propellers: 1 Water Jet (Port Side Inner) + 1 Water Jet (Port Side Outer) + 1 Water Jet (Starboard Inner) + 1 Water Jet (Starboard Outer)
